FR-D720-0.75K Mitsubishi Compact Inverter 0.75kw FR-D700 Series

Product Categories

Changsha Zhinian Automation Equipment Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: FRD720075K Mitsubishi Compact Inverter 075kw FRD700 Series
Brand: Mitsubishi
Price: 50 USD

Brand Name : Mitsubishi

Model Number : FR-D720-0.75K

Place of Origin : China/Japan

MOQ : 1/pc

Price : $50-500

Payment Terms : T/T, western union

Supply Ability : 10pc/per week

Packaging Details : Carton packaging

Display : 4 digits led

Phases : 3

Weight : 1Kg

Current Type : AC

Warrenty : 12 Months

Delivery Detail : 3-5 working days after payment

Port : Guangdong Shenzhen Dongguan

Contact Now

FR-D720-0.75K Mitsubishi Compact Inverter 0.75kw FR-D700 series

FR-D700 series is a multi-functional compact inverter, allowing you to easily enter the field of modern variable frequency drive technology.

FR-D720-0.75K Mitsubishi Compact Inverter 0.75kw FR-D700 Series

Series	FR-D700 SERIES
Type	FR-D700 COMPACT INVERTER
Minimum Rated Voltage (V)	200
Min. Permissible Voltage (V)	170
Maximum Rated Voltage (V)	240
Max. Permissible Voltage (V)	264
Current Type	AC
Phases	3
Rated Output Current ND (A)	4,2
Rated Motor Capacity ND (kW)	0,75
Control Method	V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM , MAGNETIC FLUX VECTOR CONTROL
Motor Type	INDUCTION MOTOR
Brake Chopper ED (%)	30
Integrated EMC Filter	NO
Safe Torque Off (STO)	YES
Regenerative (4Q)	NO
Integrated DC Choke	NO
Display	BUILT-IN
Display Type	4 DIGITS LED
PLC Function	NO
Integrated Digital Inputs	5
Digital Outputs (Transistor)	1
Digital Outputs (Relay)	1
Integrated Analogue Inputs	2
Integrated Analogue Outputs	1
IO Type of Terminal Block	SPRING CLAMP
Expandable	NO
RS-485	1
USB	NO
Ethernet Port	NO
Built-In Network	MODBUS-RTU
Leakage Current (mA)	1
Power Loss ND (W)	50
Standby Power Consumption (W)	5,5-10,5
Protection Class	IP20

Introduction of FR-D700

Specification

FR-D700 mains power supply specification
